Bitumen Emulsion Sprayer ( Tractor Trolley Mounted Bitumen Sprayer) is developed for track / Prime coat by hand spraying arrangement spraying application. This equipment is capable of applying uniform coating of Hot Bitumen & Emulsion on specified road surface. A perfect cleaning system cleans the bitumen pipe-line after used. Spraying pipe length up to 5 Mtr. And given drum loading system with chain pulley block of 1 ton capacity.
TANK
Tank is fabricated by 5 mm MS sheet and is coated by 40 mm Glass wool. This is done to prevent heat loss. The outer Covering is galvanized.
ENGINE
Single stage air cooled diesel engine of 6.5 hp at 1500 RPM. Engine power bitumen pumps and air compressor. Fuel consumption is 0.7 -1 liters per hour.
| specification | |
|---|---|
| Capacity | 2.5 ton to 3 Ton |
| Shape | U Shape |
| Mounted | Self-chassis mounted on wheel |
| Spraying Pressure | 0-3 Kg/cm2 |
| Engine | Standard make Air Cooled Diesel Engine Powered by 6 HP |
At TerraTech, our Bitumen Emulsion Sprayers are engineered for precision application, high efficiency, and operator-friendly use. Whether you’re working on road maintenance, patch repairs, or surface dressing, our sprayers are designed to ensure uniform coating and optimal binder distribution.
Our units are built with a pressurized cleaning system, high-capacity insulated tanks, and durable spray bars—resulting in smooth and controlled spraying operations on any type of pavement surface.
